The heaters you require can be entered on this page in a quotation request list and sent to us.
We make individual, tightly calculated prices for you and give you a written offer by e-mail. You will receive an invoice after delivery.
The prices shown in the request for quotation are non-binding guide prices (RRP). They do not correspond to the prices in our individual offers.
You can also select a single product from the list and send us a floor plan (plan or cell phone photo) - we will then select the required heaters for you and then send you the offer by e-mail.
Wenn Du unser Angebot per E-Mail, per Telefon oder schriftlich annimmst, schicken wir Dir eine Auftragsbestätigung auf dem gleichen Weg, jedoch immer schriftlich. Danach ist der Auftrag gemäß unseren General Terms and Conditions (siehe auch in der Fußzeile unten) rechtsgültig erteilt.
Processing in accordance with the guidelines of Internet commerce does not take place. The advance payment and return agreements provided for there do not apply. You will receive an invoice from us after delivery, for which we request immediate payment.
There is a DIN standard for calculating the size of radiators for hot water heating systems, but not for radiant heating systems. The required size must be determined using the room sizes depending on the intended use (living, sleeping, child, guest, bathroom, etc.).
If the DIN of hot water convection heating is used for the calculation of radiant heating according to the rules of thermodynamics, incorrect values will result. Radiant heating systems are subject to quantum physical calculations according to the Steffen-Bolzmann formula.
To help you select the required heaters, please refer to the table on the side of this page. “Calculation of the heating sizes”. There you can read off the required size of the heating elements with one click and click on the „To the offer request“ and enter the number of units in the request list.
Please note: Be generous, because a larger heater does not consume more. It switches off correspondingly earlier. However, you are on the safe side when outside temperatures are low. The price differences between the sizes are minimal.
The choice is also uncritical because infrared heating can be adapted extremely flexibly to the heating requirements of the residents.
Die unterschiedlichen Produkte der AbegSun Infrarotheizungen:
All AbegSun infrared heaters have the same basic elements:
010-OT-Infrared-Heating-Standardelement 600 Watt without Thermostat
This is the smallest and cheapest AbegSun heater. It has no thermostat and no built-in radio receiver. It is designed to be integrated into an existing smart home system. The Smart Home switch for switching the heater on/off can be mounted on top of the aluminum housing of the heater and connected with the supplied Wago click terminals.
Caution - infrared heating should not be operated without thermostat control for energy reasons!
011-OT-Infrared heating standard element 900 Watt without thermostat
This heater has no thermostat and no built-in radio receiver. It is intended to be integrated into an existing Smart Home system. The actuator of the on-site smart home system must be installed as described above for product 010.
Caution - infrared heating should not be operated without thermostat control for energy reasons!
012-OT Infrared heating standard element 1200 Watt without thermostat
This heater has no thermostat and no built-in radio receiver. It is intended to be integrated into an existing Smart Home system. The actuator of the on-site smart home system must be installed as described above for product 010.
Caution - infrared heating should not be operated without thermostat control for energy reasons!
020-WS infrared wall heating 600 Watt plug-in thermostat
Wall heater with approx. 2.5 m mains cable and plug thermostat for the wall socket. - This wall heater is very easy to operate and install with a thermostat that can be plugged into any wall socket.
However, it is important to remember that the power cable is visible if the heater is not mounted above the socket. The fact that the thermostat is supplied as a mobile device means that the temperature can be controlled flexibly from anywhere in the room. You don't have to go to the socket to set the temperature.
021-WS Infrared wall heating 900 Watt plug-in thermostat
Wall heater with approx. 2.5 m mains cable and plug thermostat for the wall socket. - This wall heater is very easy to operate and install with a thermostat that can be plugged into any wall socket.
However, it is important to remember that the power cable is visible if the heater is not mounted above the socket. The fact that the thermostat is supplied as a mobile device means that the temperature can be controlled flexibly from anywhere in the room. You don't have to go to the socket to set the temperature.
022-WS Infrared wall heating 1120 Watt plug-in thermostat
Wall heater with approx. 2.5 m mains cable and plug thermostat for the wall socket. - This wall heater is very easy to operate and install with a thermostat that can be plugged into any wall socket.
However, it is important to remember that the power cable is visible if the heater is not mounted above the socket. The fact that the thermostat is supplied as a mobile device means that the temperature can be controlled flexibly from anywhere in the room. You don't have to go to the socket to set the temperature.
030-ST infrared floor heater 600 Watt with plug-in thermostat and base plate
Portable parking heater with approx. 2.5 m mains cable and plug thermostat for the wall socket. - This wall heater requires no assembly and is very easy to operate with a plug that can be plugged into any socket.
The heater has a very attractive glass plate as the lower base plate. This is made of toughened glass and its weight ensures the stability of the heater. The heater has a large radiation area due to its curved surface.
The advantage of a parking heater is also that you can place the heater at any distance from your body in order to influence the amount of heat in addition to the set temperature.
031-ST Infrared parking heater 900 Watt with plug-in thermostat and base plate
Portable parking heater with approx. 2.5 m mains cable and plug thermostat for the wall socket. - This wall heater requires no assembly and is very easy to operate with a plug that can be plugged into any socket.
The heater has a very attractive glass plate as the lower base plate. This is made of toughened glass and its weight ensures the stability of the heater. The heater has a large radiation area due to its curved surface.
The advantage of a parking heater is also that you can place the heater at any distance from your body in order to influence the amount of heat in addition to the set temperature.
032-ST Infrared floor heater 1120 Watt with plug-in thermostat and base plate
Portable parking heater with approx. 2.5 m mains cable and plug thermostat for the wall socket. - This wall heater requires no assembly and is very easy to operate with a plug that can be plugged into any socket.
The heater has a very attractive glass plate as the lower base plate. This is made of toughened glass and its weight ensures the stability of the heater. The heater has a large radiation area due to its curved surface.
The advantage of a parking heater is also that you can place the heater at any distance from your body in order to influence the amount of heat in addition to the set temperature.
040-MTD Infrared ceiling heater 600 Watt with radio thermostat
Ceiling heating with high radiant power and maximum achievable efficiency. This is most effective with ceiling-mounted infrared heaters, as no convection heat is generated. A floor area of approx. 32 square meters is radiated from a ceiling height of 2.5 m. After some time of use, the warming of the floor (measured 24.2 - 24.8° C) creates the effect of underfloor heating.
Installation is simple. Mounting material including template for the dowel holes and Wago click terminals are supplied.
041-MTD-Infrarot-Heizung-Deckenelement 900 Watt mit Thermostat
Ceiling heating with high radiant power and maximum achievable efficiency. This is most effective with ceiling-mounted infrared heaters, as no convection heat is generated. A floor area of approx. 32 square meters is radiated from a ceiling height of 2.5 m. After some time of use, the warming of the floor (measured 24.2 - 24.8° C) creates the effect of underfloor heating.
Installation is simple. Mounting material including template for the dowel holes and Wago click terminals are supplied.
042-MTD-Infrarot-Heizung-Deckenelement 1120 Watt mit Thermostat
Ceiling heating with high radiant power and maximum achievable efficiency. This is most effective with ceiling-mounted infrared heaters, as no convection heat is generated. A floor area of approx. 32 square meters is radiated from a ceiling height of 2.5 m. After some time of use, the warming of the floor (measured 24.2 - 24.8° C) creates the effect of underfloor heating.
Installation is simple. Mounting material including template for the dowel holes and Wago click terminals are supplied.
050-LED infrared ceiling heater 600 Watt with radio thermostat + on/off LED switch
Ceiling heating with high radiant power. This is most effective with ceiling-mounted infrared heaters, as no convection heat is generated. A floor area of approx. 32 square meters is radiated from a ceiling height of 2.5 m. After some time of use, the warming of the floor (measured 24.2 - 24.8° C) creates the effect of underfloor heating. Delivery includes installation material.
In practical terms, ceiling heaters are connected to the connections of the previous ceiling lighting. If you do not want to do without the ceiling light, the heater can be fitted with an LED light strip running around the back. This is switched on and off using a separate switch supplied (no batteries required).
051-LED infrared ceiling heater 900 Watt with radio thermostat + on/off LED switch
Ceiling heating with high radiant power. This is most effective with ceiling-mounted infrared heaters, as no convection heat is generated. A floor area of approx. 32 square meters is radiated from a ceiling height of 2.5 m. After some time of use, the warming of the floor (measured 24.2 - 24.8° C) creates the effect of underfloor heating. Delivery includes installation material.
In practical terms, ceiling heaters are connected to the connections of the previous ceiling lighting. If you do not want to do without the ceiling light, the heater can be fitted with an LED light strip running around the back. This is switched on and off using a separate switch supplied (no batteries required).
052-LED infrared ceiling heater 1120 Watt with radio thermostat + on/off LED switch
Ceiling heating with high radiant power. This is most effective with ceiling-mounted infrared heaters, as no convection heat is generated. A floor area of approx. 32 square meters is radiated from a ceiling height of 2.5 m. After some time of use, the warming of the floor (measured 24.2 - 24.8° C) creates the effect of underfloor heating. Delivery includes installation material.
In practical terms, ceiling heaters are connected to the connections of the previous ceiling lighting. If you do not want to do without the ceiling light, the heater can be fitted with an LED light strip running around the back. This is switched on and off using a separate switch supplied (no batteries required).
060-MTW infrared wall heating 600 watt with radio thermostat
Wall heating with short rear mains cable with Wago click terminals. It can be connected directly to a power connection in the wall behind the heating, e.g. in the case of a renovation where a night storage heater was previously installed.
The heating is controlled using the same built-in electronic radio technology as the ceiling heating.
061-MTW infrared wall heater 900 watts with radio thermostat
Wall heating with short rear mains cable with Wago click terminals. It can be connected directly to a power connection in the wall behind the heating, e.g. in the case of a renovation where a night storage heater was previously installed.
The heating is controlled using the same built-in electronic radio technology as the ceiling heating.
062-MTW infrared wall heating 1120 Watt with radio thermostat
Wall heating with short rear mains cable with Wago click terminals. It can be connected directly to a power connection in the wall behind the heating, e.g. in the case of a renovation where a night storage heater was previously installed.
The heating is controlled using the same built-in electronic radio technology as the ceiling heating.
070-ST infrared heater with built-in radio thermostat and base plate - 600 watts
Portable parking heater with approx. 2.5 m mains cable with plug. This parking heater does not require any installation and is very easy to operate. As with the AbegSun ceiling and wall heaters, the heater has a built-in radio receiver that can be controlled via the mobile room thermostat. This enables the heating to be controlled via a weekly program.
The heater has a very attractive glass plate as the lower base plate. This is made of toughened glass and its weight ensures the stability of the heater. The heater has a large radiation area due to its curved surface.
071-ST Infrared heater with built-in radio thermostat and base plate - 900 watts
Portable parking heater with approx. 2.5 m mains cable with plug. This parking heater does not require any installation and is very easy to operate. As with the AbegSun ceiling and wall heaters, the heater has a built-in radio receiver that can be controlled via the mobile room thermostat. This enables the heating to be controlled via a weekly program.
The heater has a very attractive glass plate as the lower base plate. This is made of toughened glass and its weight ensures the stability of the heater. The heater has a large radiation area due to its curved surface.
072-ST infrared heater with built-in radio thermostat and base plate - 1120 watts
Portable parking heater with approx. 2.5 m mains cable with plug. This parking heater does not require any installation and is very easy to operate. As with the AbegSun ceiling and wall heaters, the heater has a built-in radio receiver that can be controlled via the mobile room thermostat. This enables the heating to be controlled via a weekly program.
The heater has a very attractive glass plate as the lower base plate. This is made of toughened glass and its weight ensures the stability of the heater. The heater has a large radiation area due to its curved surface.
080-STS-SET Plug switch set with separate thermostat
The plug switch is plugged into a 230 V power socket. The mains cable of the infrared heater is plugged into the socket of the plug switch.
Danach wird der mobile The mobile thermostat is then held close to the plug until the two devices have connected (paired). This separate thermostat has the advantage that the temperature can be controlled from anywhere in the room without having to go to the socket. However, it is not possible to control the heating via a weekly program with this device.
081-FTS-SET Radio thermostat set with radio switch
This set consists of a mobile thermostat with a small base and a radio switch (also known as an actuator). The actuator is permanently installed in the AbegSun infrared heaters. The SET is installed as standard in all AbegSun infrared heaters from article number 020. It can be controlled manually or via a weekly program
082-EAW-SET On/off radio switch set with additional radio switch
This switch with radio receiver can be used to switch a light source that is not part of the infrared heating element on or off in a room. Any lighting can thus be switched independently of the infrared heating.
The switch can be mounted on the wall (usually next to the door) or used as a mobile unit. It does not require batteries.
083-EAS switch On/Off radio wall switch, single
The switch for a room input and output is supplied as standard with every LED heating element.
This additional switch is required if the living room has several inputs and outputs. The LED lighting of the infrared heating can be switched from an additional input. This then provides the same radio signal as the switch, which is already present as standard on delivery and has been installed on the wall next to another door in the room.
